Alcoa Camloc - Stainless Steel Stud Assembly, Turnlock Fastener | 2700-5S

The Camloc 2700-5S Stud is a slotted recess, flush head fastener stud from the Calmoc 2700 series. Has a length .730" of and a total grip thickness of .150"-.179". Constructed from stainless steel. These light-duty Camloc studs are rated for 200 pounds working strength (ultimate tensile strength 300 pounds). The slot head allows use with standard flat-blade screwdrivers (no special tools needed).

Features

• Product Type: Stud
• Fastener Series: 2700
• Stud Size: 5
• Stud Type: Countersunk Flush
• Head Type: Slotted
• Head Shape: Flat
• Body Material: Stainless Steel
• Total Stud Length: .730in [18.54mm]
• Total Material Thickness
• w/ fixed receptacle: .150-.179in [3.81-4.54mm]
• w/ adjustable receptacle: .130-.430in [3.30-10.92mm]
• Working Strength: 200 lbs
• Ultimate Tensile Strength: 300 lbs
